2 — INSTALLATION AND WIRING
pg. 13
Return to TOC Curtis Model 1226BL – July 2024
e following table describes the drivers.
Note: To congure a pin’s PWM mode, use the parameter listed in the last column.
Pin Typical Function Pin Mode Parameter
J3-2 Valve driver/Status LED driver Valve Driver Compensation, Drivers Setting menu
J3-11
Depends upon the model:
• 1226BL-22XX and 1226BL-41XX:
Pump contactor driver
• 1226BL-61XX: Main contactor driver
Depends upon the model:
• 1226BL-22XX and 1226BL-41XX: Pump
Contactor Driver Compensation, Drivers
Setting menu
• 1226BL-61XX: Battery Voltage
Compensated, Main Relay menu
J3-12 EM brake driver Battery Voltage Compensated, EM Brake menu
e following list describes considerations for the drivers:
• e drivers provide diagnostic faults for open coils. To enable a driver’s fault protection, use
the Drivers Setting menu parameters that have names ending with “Checks Enable”.
• You can use the Outputs menu to monitor the outputs’ values.
e following table describes the drivers’ specications.
Table 2 Driver Specifications
Specification Value
Active level Low = On
Max Current 1.5A continuous
Output Low Voltage < 0.5V at full current and 100% PWM
Frequency 16 KHz
Pulse Width Resolution 0.5% minimum over a 2% to 99% duty cycle range (8 bit resolution)
Maximum Voltage 125% of nominal battery voltage +5V
Maximum Reverse Voltage −0.5V
Open Pin Response Low / Off (pulled to B–)
Logic High Threshold Depends upon the model:
• 1226BL-22XX: 7V
• 1226BL-41XX: 12V
• 1226BL-61XX: 17V
Logic Low Threshold Depends upon the model:
• 1226BL-22XX: 4V
• 1226BL-41XX: 7V
• 1226BL-61XX: 10V
Input Impedance Depends upon the model:
• 1226BL-22XX: > 50K
• 1226BL-41XX: > 100K
• 1226BL-61XX: > 150K
