2 — INSTALLATION AND WIRING
pg. 11
Return to TOC 1212P Manual – Sept. 2022
Status LED
e controller has the capability to drive a panel indicator LED, which can be used to tell the operator,
at a glance, the controller’s status. is LED always indicates whether the controller is powered on or
o. It will also provide diagnostics information via ash codes (see Chapter 7).
If a status LED is used, it should be installed with the proper resistor in series. e controller’s LED
driver is capable of a maximum current of 15 mA. e recommended resistor—designed to limit
driver current to 15 mA when active—is 2.4 kΩ, 0.5 W. Alternatively, an LED with a built-in resistor
can be used; it should be rated for 24V operation.
Horn / Lift Lockout Output
e controller’s horn driver—Pin 3—is designed to drive a low current DC horn at 1 Hz. e horn
sounds a warning when the reverse direction is selected and when the throttle autocalibration feature
is being used. e horn driver sinks a maximum current of 15 mA. Using a horn with a higher current
requirement will damage and disable the driver. e horn driver can be used to drive a brake light
instead of a horn; see Brake menu.
Pin 3 can also be used to drive a relay to control the pump contactor. Setting the parameter Li
Lockout Enable = On will enable this feature and disable the horn output. Also, if the parameter
External Li Lockout = On, the li lockout output will be active if the li lockout input is low. e
maximum current for this low-side driver is 50 mA.
Reverse Switch / Neutral Input
If a single-ended or unipolar throttle is used, a reverse switch connected to Pin 12 can be used to
change the driving direction to reverse.
Pin 12 can also be used for a neutral input. When the parameter Neutral Input = On, the 1212P will
check this input from a wigwag throttle that has neutral output (such as the Curtis ET-190E). If the
neutral input is low, the 1212P will shut o output regardless of throttle input.
