2 — INSTALLATION AND WIRING
1212 Manual – Sept. 2022 Return to TOC
pg. 8
Voltage Throttle
Wiring for a voltage throttle is shown in Figure 5. With this throttle, the controller can be programmed for
a rottle Type 5–9 input signal; see page 16.
1234567
8910 11 12 13 14
+
VOLTAGE
THROTTLE
Pot Wiper input (Pin 1)
−
B−
Figure 5
Wiring for Voltage
rottle.
e PotHigh and PotLow parameters are used to set the voltage range of these throttles. If the pot wiper
voltage is higher than the programmed PotHigh value or lower than the programmed PotLow value, the
controller will issue an out-of-range throttle fault. In order for the controller to be able to detect out-of-range
throttle faults, the throttle must have a range within the limits of 0.4–4.6 V.
Note: If a 0–5V throttle is used, it is the responsibility of the OEM to provide appropriate throttle fault
detection.
Speed Limit Pot
A speed limit pot allows the operator to adjust the speed of the vehicle at full throttle. e speed limit pot
should be sized so that it does not aect throttle input resistance and thus the throttle response; a 100kΩ pot
is recommended.
e speed limit pot is at its maximum speed setting when its wiper is shorted to the throttle’s pot high
connection (Pin 2). When the speed limit pot is in its maximum speed position, the vehicle’s speed at full
throttle corresponds to the programmed maximum speed setting.
The speed limit pot is at its minimum speed setting when its wiper is shorted to the throttle’s pot low
connection (Pin 8). When the speed limit pot is in its minimum speed position, the vehicle’s speed at full
throttle corresponds to the programmed minimum speed setting. For information on the programmable
speed parameters, see Chapter 3.
e speed limit pot varies the vehicle’s speed linearly over the range between the minimum and maximum
speed settings in each mode, in forward and in reverse.
If a speed limit pot is not used, the Speed Limit Pot parameter should be programmed O to disable the
fault check at the speed limit pot.
