Introduction of Your Refrigerator's Functions Introduction of Your Refrigerator's Functions
Control buttons
1
Refrigerator temperature control
2 Freezer temperature control
3 Energy saving mode
4 Auto mode
5 Ice-making switch
6 Child Lock
Display items
7
Fast-cooling icon
8 Fast-freezing icon
9 Energy-saving icon 14 Freezer compartment icon
15 Refrigerator indicate
16 Freezer indicate
10 Auto icon
11 Ice-making icon
12 Locked icon
13 Refrigerator compartment icon
Off icon: means refrigerator
shut down
17
18 Refrigerator temperature
19 Freezer temperature
Initial power-on status
All on
Energy saving mode
In order to save energy, this mode sets the temperature in the refrigerator at
7℃ and the temperature in the freezer at -15℃, “AUTO” mode default
settings are 5℃ and -18 ℃, respectively .
To activate the “Energy Saving”mode, Press the ENERGYSAVING MODE
buttonand the“ENERGY SAVING”icon will illuminate. Enabling the
energy saving mode for the refrigerator will automatically disable all other
modes.
To de-activate “Energy Saving” mode, do any of the following:
1. Select another mode.
2. Press REF. TEMP. or FRZ. TEMP. to exit setup.
3. ENERGYSAVING MODE button to exit the energy-saving modePress
when any of the above situations occur.
4. AUTO MODE to exit the energy-saving mode when any of above
situations occurs.
Press
Auto mode
This function will set the temperature of the refrigerator to 5℃and the freezer
compartment to -18℃ .If the refrigerator compartment is turned off, the auto
mode will still be in effect for the freezer compartment.
To activate Auto Mode: Press AUTO MODE and the “AUTO ”icon will
illuminate, indicating the activation of “AUTO MODE”. Selecting “AUTO
MODE”will automatically de-activate all other modes.
1
3
5
7 9 13 15 17 18 10 8
11 14 16 19 12
2
4
6
To toggle between Celsius and Fahrenheit display, press and hold the
“AUTO MODE”button for 3 seconds. .
To de-activate AUTO MODE:
1. Select another mode
2. Press REF. TEMP. or FRZ. TEMP. to exit setup.
Fast-cooling mode
This mode is used to counteract a sudden rise in the temperature of the
refrigerator compartment,such as when a large amount of items is placed into
the refrigerator after a trip to the supermarket.The compressor will work for
longer cycles to maintain the desired temperature.
To activate the mode: Press REF Temp for three seconds and the“Super
Cool ”icon will illuminate. When the fast-cooling mode is activated for the
refrigerator compartment, all other modes are automatically de-activated.
Locking and unlocking
Under unlocked status (indicator 6 is off), push down F briefly to lock and indicator 6
is on. Under locked status, push down F for three seconds to unlock. If no other keys are pushed
within 25sec under the unlocked status, it will enter into the locked status automatically.
The“Fast-Cooling”mode can be de-activated by doing any of the following:
1. Activate the “Energy-Saving” or “AUTO” mode;
2. Press REF. TEMP. to adjust the temperature;
3. Hold down REF. TEMP. for three seconds.When the temperature of the
refrigerator compartment reaches the set temperature,“Fast-cooling”mode
will be automatically de-activated.
