14 49-3000224 Rev 3
REVERSING THE DOOR
Reversing the door
Tools needed:
n Standard #2 n Tape-tipped
n Phillips screwdriver n putty knife
1
Open the door and remove the filler plugs opposite the
hinges. With the door completely open, remove the
bottom screw from each hinge on the dryer face. Insert
these screws about half way into the TOP holes, for each
hinge, on the opposite side (where you removed the filler
plugs). Apply firm pressure to get the screw started in
new holes.
2
Loosen top screw from each hinge on the dryer face half
way. With one hand holding the top of the door and the
other hand holding the bottom, remove the door from the
dryer by lifting it UP and OUT.
3
Remove the blind plate from the hinge side of the dryer
by removing its two screws. Remove the strike plate
from the opposite side of the dryer by removing its two
screws. Reinstall the plates, on the opposite sides,
using two screws in each plate.
4
Rotate the door 180°. Insert it on the opposite side of the
opening by moving the door IN and DOWN until the top
hinge and the bottom hinge are resting on the top screws
inserted in step 1.
5
Remove the remaining screws from the side of the
opening from which the door was removed. With these
screws, secure each hinge at the bottom. Tighten the two
top screws of each hinge. Reinsert the plastic plugs on
the side from which the door was removed.
INSTALL AND TIGHTEN
BOTTOM SCREWS AND
TIGHTEN TOP SCREWS
INSERT PLUGS
INTO HOLES ON
OPPOSITE SIDE
REMOVE BOTTOM SCREW FROM
EACH HINGE AND INSTALL HALF
WAY INTO EACH TOP OF OPPOSITE
HINGE HOLES
REMOVE 4 PLUGS AND
KEEP FOR INSERTION
INTO THE
OPPOSITE
SIDE
LOOSEN EACH TOP
HINGE SCREW HALF
WAY AND LIFT THE
DOOR UP AND OFF
FRONT PANEL
SWITCH
STRIKE
PLATE
BLIND
PLATE
ROTATE DOOR 180º AND
HANG IT ON TOP HINGE
SCREWS
