9. Screw in and tighten the center hinge pin
using an adjustable wrench.
10. For type A top hinge, attach the top hinge
to the freezer door. Lower the freezer door
over the center hinge pin at a
90° angle,
and close the door, holding it in place.
Type A hinge
11. For type B top hinge, remove the hinge pin
from the top hinge. Put the hinge pin
through the hole on the opposite side. Flip
the top hinge over and attach it to the
freezer door. Lower the freezer door over
the center hinge pin at a
90° angle, and
then close the door, holding it in place.
Type B hinge
12. Place the lower hinge cover between the
freezer door and refrigerator door to keep it
level while attaching the top hinge.
10
DOOR REMOVAL
