4
INSTALLATION INSTRUCTIONS
CAUTION
To avoid risk of personal injury, property damage, or product damage due to the weight of this device
and sharp edges that may be exposed:
Air conditioners covered in this manual pose an excessive weight hazard. Two or more people are
needed to move and install the unit.To prevent injury or strain, use proper lifting and carrying
techniques when moving unit.
Carefully inspect location where air conditioner will be installed. Be sure it will support the weight of
the unit over.
Handle air conditioner with care. Wear protective gloves whenever lifting or carrying the unit. AVOID
the sharp metal fins of front and rear coils.
Make sure air conditioner does not fall during installation.
Tools and Parts:
Gather the required tools and parts before starting installation. Read and follow the instructions
provided with any tools listed here.
TOOLS NEEDED
Flat-blade and Phillips screwdrivers
Tape measure
Level
Drill and 3/16 , 1/8 , 3/32 , or smaller drill bit
Through-the-wall Installation:
In addition to the tools listed above, the following tools are needed for through-the-wall installation.
TOOLS NEEDED
Saw
Caulk
1 (2.5 cm) or thicker lumber
#10 X 1 wood screws (7)
Parts Supplied:
Check that all parts are included in parts package:
Hardware
Qty.
3
7
pan - head
Phillipsscrews
Qty.
1
1
round - head
screws
pan - head
Philli
p
s
screws
5
Top channel
Window sash seal
Hardware
Foam seal
1
side curtains
2
5
1
2
Window lock bracket
Safety Lock
(for Vinyl-Clad window)
weather seals
Remote Control
1
Remote Battery
2
MODE
ENERGY SAVER
CLEAN AIR
FOLLOW ME
SLEEP
LED
CLOCK
CANCEL
TIMER
FAN
RESET
LOCK
CLOCKCLOCK
E
ONON
OFF OFF
SET TEMP.SET TEMP.
FAN SPEEDFAN SPEED
AUTO
F
1
2
or
