Je bekijkt pagina 57 van 113
Product Manual — Doc. 9243B Horizon® 2 Dimmers, Switches, and Keypads • 57
HZ2-AUX Specifications
Product specifications for the HZ2-AUX.
Product Specifications
Power Requirements
120VAC, 50/60 Hz
Controls
Pushbutton (2) Pushbuttons, located under the button assembly;
Pushbuttons are actuated by the button assembly that is installed
2
Button Assembly (1) Button assembly included;
Compatible with Style6 button assemblies
NOTE: The HZ2-AUX cannot be used to control a load directly. It must be used in conjunction with a
HZ2-DIMEX, HZ2-DIMUEX, or HZ2-SWEX.Supplied button caps are not engravable.
LED Indicator and Light Sensor
LED Feedback None;
For multiway control using a device that provides LED backlighting, use a
HZ2-KPCNor HZ2-KPEX
Light Sensor None;
For multiway control using a device that has a light sensor, use a HZ2-KPCNor
HZ2-KPEX
Wire Distance
Maximum wire length of 250 ft (77 m) between HZ2-AUX and Primary Device
Connections
Line (1) Screw clamp terminal, consists of (2) wire inserts and (1) black screw head;
Line power input;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Remote (1) Screw clamp terminal, consists of (2) wire inserts and (1) blue screw head;
Remote input from HZ2-AUX or HZ2-KPEX;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Ground (1) 12 AWG flying lead, Class 1, green with yellow stripe;
Ground;
Wire nut included
Environmental
Temperature 32° to 86°F (0° to 30°C)
Humidity 10% to 90% RH (noncondensing)
