Product Manual — Doc. 9243B Horizon® 2 Dimmers, Switches, and Keypads • 51
HZ2-KPEX Specifications
Product specifications for the HZ2-KPEX.
Product Specifications
Power Requirements
Line Power 120VAC, 50/60 Hz;
Requires neutral wire connection
DC Power 60VDC, 30 mA ;
Requires a SolaHD® SDP™ 1-48-100T power supply (sold separately)
Controls
Airgap (1) Switch at the bottom of the device;
Controls power to the device and connected loads
Pushbutton (9) Pushbuttons, located under the button assembly;
Pushbuttons are actuated by the button assembly that is installed
Button Assembly (1) Button assembly included;
Compatible with Style1–6 button assemblies
Setup (1) Pushbutton;
Front of the faceplate must be removed to access the pushbutton;
Can be used to set the local LED backlight color theme or calibrate the ambient light
sensor
NOTE: The HZ2-KPEX cannot be used to control a load directly. It must be used in conjunction with
a HZ2-DIMEX, HZ2-DIMUEX, or HZ2-SWEX.Supplied button caps are not engravable.
LED Indicator and Light Sensor
LED Feedback (5) RGB LED backlights;
Supports one local color theme for all LEDs;
Supports one alternate color theme for each backlit position
Light Sensor (1) Photosensor with adjustable sensitivity;
Detects the ambient room light level to activate day or night mode and autodimming
the backlight
NOTE: Light sensor performance may be affected by obstructions placed below the keypad.
Wireless
RF Transceiver infiNET EX® 2-way RF, 2.4 GHz ISM Channels 11-26 (2400 to 2483.5 MHz), default
channel 15;
IEEE 802.15.4 compliant
Range (typical) 150 ft (46 m) indoor, 250 ft (76 m) outdoor to nearest mesh network device;
Subject to site-specific conditions and individual device capabilities
