Product Manual — Doc. 9243B Horizon® 2 Dimmers, Switches, and Keypads • 39
Wireless
RF Transceiver infiNET EX® 2-way RF, 2.4 GHz ISM Channels 11-26 (2400 to 2483.5 MHz), default
channel 15;
IEEE 802.15.4 compliant
Range (typical) 150 ft (46 m) indoor, 250 ft (76 m) outdoor to nearest mesh network device;
Subject to site-specific conditions and individual device capabilities
1
Gateway Requires a Crestron Wireless Gateway (sold separately)
Connections
Load (1) Screw clamp terminal, consists of (2) wire inserts and (1) red screw head;
Load output;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Line (1) Screw clamp terminal, consists of (2) wire inserts and (1) black screw head;
Line power input;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Neutral (1) Screw clamp terminal, consists of (2) wire inserts and (1) silver screw head;
Neutral input;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Remote (1) Screw clamp terminal, consists of (2) wire inserts and (1) blue screw head;
Remote input from HZ2-AUX or HZ2-KPEX;
Accepts (1) 14-12 AWG wire per insert, do not insert wires behind screw head
Ground (1) 12 AWG flying lead, Class 1, green with yellow stripe;
Ground;
Wire nut included
Environmental
Temperature 32° to 86°F (0° to 30°C)
Humidity 10% to 90% RH (noncondensing)
Construction
Mounting Mounts in a 1- to 4-gang U.S. electrical box (not included);
3.5in. (26mm) electrical box depth recommended;
Derating required in multigang applications
Faceplate Requires a Horizon®2 faceplate (HZ2-FP-G, sold separately, metal backplate included
with faceplate);
Multigang installations require a 2-, 3-, or 4-gang Horizon® 2 faceplate with metal
backplate (HZ2-FP-G, sold separately);
The metal backplate is required for all installations where the electrical box is flush
with or recessed from the wall surface;
The metal backplate is not recommended for electrical boxes that protrude beyond
the wall surface
Dimensions
Height 4.13 in. (105 mm), air-gap switch extends 0.26in. (7mm) from bottom of keypad
Width 1.80 in. (46 mm)
