8 • HD-EARC KIT Product Manual — Doc. 9472A
USB (1) USB Type-A connector, female;
For firmware loading
COM (1) 3-pin 3.5mm detachable terminal block;
Bidirectional RS-232 port;
Supports RS-232 up to 115.2kbaud;
Passes communications through to the COM port of the transmitter
IR IN (1) 2-pin 3.5 mm detachable terminal blocks;
Comprises (1) IR input port;
For connection from a Crestron IR control port or other IR signal source;
Passes the IR input signal to the IROUT port on the transmitter;
Supports IR up to 60kHz
IR OUT (1) 2-pin 3.5 mm detachable terminal blocks;
Comprises (1) IR output port;
For connection to an IR emitter (IRP2, sold separately);
Transmits the IR signal from the IRIN port on the transmitter;
Supports IR up to 60kHz
Controls and Indicators - Transmitter
HDMI/OPTICAL (1) 2-position slider switch;
Selects which audio output connector to prioritize on the HD-TXC-EARC
PWR (1) Green/amber bi-color LED;
Amber indicates that the device is booting;
Green indicates that the device is operational
DM OUT (2) LEDs on RJ-45 connector, one green and one amber;
Green indicates that DM Essentials link is established;
Flashing amber indicates non-HDCP video;
Solid amber indicates HDCP video
HDMIIN/EARC OUT (1) Green LED, indicates that the device is receiving an HDMI signal and/or
transmitting an eARC digital audio signal
OPTICAL OUT (1) Green LED, indicates an S/PDIF digital audio signal is present at the OPTICAL OUT
connector
Controls and Indicators - Receiver
PWR (1) Green/amber bi-color LED;
Amber indicates that the device is booting;
Green indicates that the device is operational
DM IN (2) LEDs on RJ-45 connector, one green and one amber;
Green indicates that DM Essentials link is established;
Flashing amber indicates non-HDCP video;
Solid amber indicates HDCP video
HDMIOUT/EARC IN (1) Green LED, indicates that the device is transmitting an HDMI signal and/or
receiving an eARC digital audio signal
OPTICAL IN (1) Green LED, indicates that the device is receiving a S/PDIF digital audio signal
