DALI Lighting Design Guide
Doc. 7386H | crestron.com
13
DIN-DALI-2 Interface
The DIN-DALI-2 is a DALI interface for Crestron systems that provides control of up to two independent DALI loops.
Housed in a DIN rail enclosure, the DIN-DALI-2 is a low-profile Ethernet companion to the DIN-AP3 processor or
any 3-Series Control System
®
device. In addition to controlling the DALI data bus, it includes an integrated DALI
power supply. The single-wire connectivity simplifies both new and retrofit installations. Power-over-Ethernet (PoE)
versatility assists in situations with existing CAT5 infrastructure:
• Cresnet or PoE communication for single-wire installation
• Crestron DALI Commissioning Tool for easy setup
• DIN rail mounting 9 M wide
• CEC Title 24 2013 compliant
For the DALI protocol to communicate with other protocols, a control interface is necessary. The interface acts as
a language translator, allowing the DALI protocol to be understood and used by other protocols such as Cresnet,
BACnet, and Ethernet. Using the DALI protocol, the primary building systems can easily communicate. The
DIN-DALI-2 is powered through either Cresnet or PoE. This simplifies wiring to the DIN-DALI-2 module.
NOTE: For more information, refer to the DIN-DALI-2 product page on the Crestron website.
DIN-DALI-2
