2
Conguration: Compact 2-way passive speaker
Power Handling*: 200 Watts Continuous, 400 Watts Program, 800 Watts Peak
*To reach the rated power, there must be an infrasonic lter set to 65 Hz, 12 dB / Octave Butterworth minimum ltering. If the CPL 8
+
is used with a crossover for a
Subwoofer, then the high pass section needs to meet this criteria at a minimum. A higher frequency and/or lter slope is acceptable.
Nominal Impedance: 8 Ohms
Sensitivity (1W/1m): 95 dB
Maximum SPL (1m): 118 dB @ 200 Watts; 124 dB @ 800 Watts Peak
Frequency Response*: 131 Hz - 20 kHz, ±3 dB
*1m on-axis, swept-sine in anechoic environment
Frequency Range*: 67 Hz - 20 kHz, -10 dB
*1m on-axis, swept-sine in anechoic environment
Box Tuning Frequency: 65 Hz
Nominal Coverage Pattern (-6 dB): 60° H x 60° V
LF Driver: 1 x 8" (200 mm) Woofer - Crest Audio CPL850B
LF Driver Voice Coil: 2" (50 mm)
HF Driver: 1 x 1" (25.4 mm) Compression Driver - Crest Audio CQ3402
HF Driver Voice Coil: 1.3" (34 mm)
Input Connections: 2 x 4-pin twist-lock (NL-4 style) & 1 x 4-pin Euroblock
Input, Pin 1+ = (+) positive; Pin 1- = (-) negative / Loop rough, Pin 2+ = (+) positive; Pin 2- = (-) negative
Enclosure Material: 0.6" (15 mm) Plywood
Finish: Textured polyurea paint, available in Black & White
Black Finish: RAL: 9004 Signal Black (Pantone: Black 6)
White Finish: RAL: 9003 Signal White (Pantone: 705)
Front: Full-coverage perforated steel grille, backed with acoustically neutral foam
Mounting Provisions: Nine (9) M8 suspension points (2 top, 2 bottom, 2 le, 2 right, and 1 rear) and additional
set of four (4) M6 mounting points rear for optional Peavey Versamount 35
Overall Dimensions (HWD):
Front - 16.54" x 10.59" x 10.83" (420 x 269 x 275 mm)
Rear - 16.54" x 7.28" x 10.83" (420 x 185 x 275 mm)
Net Weight: 24.6 lbs (11.2 kg)
EN
SPECIFICATIONS
