4
EN
RIGGING & MOUNTING
Installation methods for optional mounting accessories
Installation Method 1 - U-Bracket
Installation Method 2 - Versamount 35
Installation Method 3 - Pole Mount Adapter
M8 knob-headed bolt
Lockwasher
Bolt hole
Threaded
angle set hole
Pole Mount Adapter
Pole tightening knob
Lockwasher
Top v iew
Versamount 35
M8 knob-headed bolt
Lockwasher
M8 knob-headed bolt
4 x Lockwasher
4 x Screw
Insert for
safety chain
or wire rope
M8 knob-headed bolt
Stand Pole
Threaded into center
insert of cabinet plate
Note: This CPL
+
model can also be used with the
Versamount 70 ceiling or wall-mount bracket. Both
mounting plates on the Versamount 70 include a
hole pattern that matches the Versamount 35
mounting hole spacing. The use of the Versamount
70 can be helpful when the Versamount 35 does not
have enough adjustment range to angle or aim the
cabinet as desired.
Note: The U-Bracket is a standard accessory, which has been included in the product package.
Peavey Versamount 35, and Pole Mount Adapter are not included. These are optional accessories and need to be ordered separately.
