5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Retherm Oven
FL-2391
Rev. 0 (4/16)
Page 3 of 14
INSTALLATION INSTRUCTIONS
UNIT SPECIFICATIONS: Units below use six (6) elements (3000 watts each). Units are rated 18,000 watts.
MODEL NOS.
ELECTRICAL SPECS
(AC SERVICE)
ELEC. LOAD
POWER SUPPLY REQUIREMENT
ALL 3 PHASE IS 3 WIRE + GROUND
VOLTS PHASES HZ AMPS VOLTS AMPS PHASES VOLTS RECEPTACLE
RR1332DE(DX)2083 208 3 60 50 208 60 3 208 15-60R
RR1332DE(DX)2403 240 3 60 44 240 60 3 240 15-60R
RR1332DE(DX)4803 480 3 60 22 480 30 3 480 L16-30R
UNIT SPECIFICATIONS: Units below use six (6) elements (2000 watts each). Units are rated 12,000 watts.
RR1332DE(DX)12K2083 208 3 60 34 208 50 3 208 15-50R
RR1332DE(DX)12K2403 240 3 60 29 240 50 3 240 15-50R
RR1332DE(DX)12K4803 480 3 60 15 480 30 3 480 L16-30R
UNIT SPECIFICATIONS: Units below use six (6) elements (1325 watts each). Units are rated 8,000 watts.
RR1332DE(DX)8K2081 208 1 60 40 208 50 1 208 6-50R
RR1332DE(DX)8K2401 240 1 60 35 240 50 1 240 6-50R
All models are designed for AC Service. Model numbers may have the letters: Z or S.
HOW TO INSTALL OVENS:
1. Remove all packing material from inside and outside
of oven.
2. Position oven on level oor.
3. After shipping, you may have to adjust legs to ensure
proper t of rack into cabinet.
4. Plug power cord into proper wall receptacle.
HOW TO CHANGE FROM °F TO °C (if needed)
1. Push the switch on; the light will come on.
2. Push and hold the “SET” button and the button in the
lower left hand corner together for 5 seconds.
You have now entered into the menu.
3. Scroll over the”Unit” and change it to “C” , then scroll
to the “END”.
FIRST-TIME OPERATION
NOTE: A new oven needs to “burn off” manufacturing
oils and excessive adhesive before its rst use. Do NOT
load food into oven until this has been done!
1. Push the switch to on; the light will come on.
NOTE: The letters “LOtPr” (low temperature) will show
on the control panel until it reaches 140°F (60°C).
2. Press the “COOK” button.
3. Turn the control knob to show 350°F. Push the knob 3
times to heat the unit. Run the unit like this for one
(1) hour.
4. Turn the unit off and let cool.
5. Wipe the inside clean with detergent and hot water.
VENTING YOUR OVEN:
1. The purpose of ventilating hoods is to direct and
capture smoke, grease-laden vapors, heat, odors,
or fumes.
2. Low temperature equipment (maximum
temperature 250°F/121°C) does not produce heat,
odors, fumes, grease-laden vapors or smoke and
is not required to be vented.
3. Most jurisdictions consider our low-temperature
ovens (maximum temperature is 350°F/177°C) as
low-heat appliances not requiring vent hoods.
4. Installation must conform with local codes. The
authority having jurisdiction of enforcement of
the codes will have the responsibility for making
interpretations of the rules.
