5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Retherm Oven
FL-2357
Rev. 5 (2/15)
Page 3 of 14
INSTALLATION INSTRUCTIONS
UNIT SPECIFICATIONS: Units below use six (6) elements (2000 watts each). Units are rated 12,000 watts.
MODEL NOS.
ELECTRICAL SPECS
(AC SERVICE)
ELEC. LOAD
POWER SUPPLY REQUIREMENT
ALL 3 PHASE IS 3 WIRE + GROUND
VOLTS PHASES HZ AMPS VOLTS AMPS PHASES VOLTS RECEPTACLE
RO151FUA18DE2083
RO151FPUA18DE2083
RO151F1332DE2083
208 3 60 34 208 50 3 208 15-50R
RO151FUA18DE2403
RO151FPUA18DE2403
RO151F1332DE2403
240 3 60 29 240 50 3 240 15-50R
RO151F1332DE4803 480 3 60 15 480 30 3 480 L16-30R
UNIT SPECIFICATIONS: Units below use six (6) elements (1325 watts each). Units are rated 8,000 watts.
RO151FUA18DE8K2081
RO151FPUA18DE8K2081
RO151F1332DE8K2081
208 1 60 39 208 50 1 208 6-50R
RO151FUA18DE8K2401
RO151FPUA18DE8K2401
RO151F1332DE8K2401
240 1 60 34 240 50 1 240 6-50R
All models are designed for AC Service. Model numbers may have the letters: DX, P, L, M, Z or S.
VENTING YOUR OVEN:
1. This cabinet passes the EPA 202 test and complies
with section 59 of UL710B for emission of grease-
laden air.
2. According to UL, this cabinet does not need to be
placed under a ventilation hood.
3. Installation must conform with local codes. The
authority having jurisdiction of enforcement of
the codes will have the responsibility for making
interpretations of the rules.
HOW TO INSTALL OVENS:
1. Remove all packing material from inside and outside
of oven.
2. Position oven on level oor; install the oven interior
(pan slides) if not already installed.
3. Plug power cord into proper wall receptacle.
HOW TO CHANGE FROM °F TO °C (if needed)
1. Push the switch on; the light will come on.
2. Push and hold the “SET” button and the button in the
lower left hand corner together for 5 seconds.
You have now entered into the menu.
3. Scroll over the”Unit” and change it to “C” , then scroll
to the “END”.
FIRST-TIME OPERATION
NOTE: A new oven needs to “burn off” manufacturing
oils and excessive adhesive before its rst use. Do NOT
load food into oven until this has been done!
1. Push the switch to on; the light will come on.
NOTE: The letters “LOtPr” (low temperature) will show
on the control panel until it reaches 140°F (60°C).
2. Press the “COOK” button.
3. Turn the control knob to show 350°F. Push the knob 3
times to heat the unit. Run the unit like this for one
(1) hour.
4. Turn the unit off and let cool.
5. Wipe the inside clean with detergent and hot water.
