5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Convection
Humidity Oven
FL-2368
Rev. 1 (8/14)
Page 3 of 13
HOW TO INSTALL CABINETS:
1. Remove all packing material from inside and outside
of cabinet.
2. Position cabinet on level oor; install the cabinet
interior (pan slides) if not already installed.
3. Plug power cord into proper wall receptacle.
INSTALLATION INSTRUCTIONS
VENTING YOUR OVEN:
1. The purpose of ventilating hoods is to direct and
capture smoke, grease-laden vapors, heat, odors, or
fumes.
2. Low temperature equipment (maximum temperature
250°F/121°C) does not produce heat, odors, fumes,
grease-laden vapors or smoke and is not required to be
vented.
3. Most jurisdictions consider our low-temperature ovens
(maximum temperature is 350°F/177°C) as low-heat
appliances not requiring vent hoods.
4. Installation must conform with local codes. The
authority having jurisdiction of enforcement of
the codes will have the responsibility for making
interpretations of the rules.
UNIT SPECIFICATIONS: All units use six (6) elements (1325 watts each). All units are rated 8000 watts.
MODEL NOS.
ELECTRICAL SPECS
(AC SERVICE)
ELEC. LOAD
POWER SUPPLY REQUIREMENT
ALL 3 PHASE IS 3 WIRE + GROUND
CONVECTION OVENS Volts Ph Hz. Amps Volts Amps Ph Volts NEMA
CO151FUA12D2081
CO151FUA12D2401
208
240
1
1
60
60
39
34
208
240
50
50
1
1
208
240
6-50P
6-50P
CO151FUA12D2083
CO151FUA12D2403
208
240
3
3
60
60
23
20
208
240
30
30
3
3
208
240
L15-30P
L15-30P
HALF-SIZE OVENS
Are rated at 4700 watts (Six [6] heaters at 735 watts each)
CO151HUA6D2081
CO151HUA6D2401
208
240
1
1
60
60
24
21
208
240
30
30
1
1
208
240
6-30P
6-30P
CO151HUA6D2083
CO151HUA6D2403
208
240
3
3
60
60
15
13
208
240
20
20
3
3
208
240
L15-20P
L15-20P
CO151H189D2081
CO151H189D2401
208
240
1
1
60
60
24
21
208
240
30
30
1
1
208
240
6-30P
6-30P
CO151H189D2083
CO151H189D2403
208
240
3
3
60
60
15
13
208
240
20
20
3
3
208
240
L15-20P
L15-20P
CO151XUA5D2081
CO151XUA5D2401
208
240
1
1
60
60
24
21
208
240
30
30
1
1
208
240
6-30P
6-30P
CO151XUA5D2083
CO151XUA5D2403
208
240
3
3
60
60
15
13
208
240
20
20
3
3
208
240
L15-20P
L15-20P
CO151X185D2081
CO151X185D2401
208
240
1
1
60
60
24
21
208
240
30
30
1
1
208
240
6-30P
6-30P
CO151X185D2083
CO151X185D2403
208
240
3
3
60
60
15
13
208
240
20
20
3
3
208
240
L15-20P
L15-20P
All models are designed for AC Service. Model numbers may have the letters: B, L, M, P, R, T, U Z or S.
HOW TO CHANGE FROM °C TO °F (if needed)
1. Push the switch on; the light will come on.
2. Push and hold the “SET” button and the button in the
lower left hand corner together for 5 seconds.
You are now entered into the menu.
3. Scroll over the”Unit” and change it to “C” , then scroll
to the “END”.
