5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Convection Oven
FL-2378
Rev. 1 (2/15)
Page 3 of 14
• MANUAL FILL: Fill water pan with three (3) gal-
lons of HOT water (see CAUTION).
• AUTO FILL: Attach water valve on back bottom of
unit to water supply (see “How to use Automatic ll
kit on page 7).
FOR MODEL CO151XWUA5DE(or DX)1201 ONLY
WHEN USING HUMIDITY OPTION:
INSTALLATION INSTRUCTIONS
Use of treated water is recommended for
proper operation and to maintain warranty.
It will reduce scaling.
CAUTION
HOW TO CHANGE FROM °F TO °C (if needed)
1. Push the switch on; the light will come on.
2. Push and hold the “SET” button and the button in the
lower left hand corner together for 5 seconds.
You have now entered into the menu.
3. Scroll over the”Unit” and change it to “C” , then scroll
to the “END”.
ELECTRICAL SPECIFICATIONS:
Model Nos. Volts Watts Amps Hertz Phase NEMA
CO151XUA5DE1201
CO151X185DE1201
C0151XWUA5DE1201
CO151XUA5DX1201
CO151X185DX1201
C0151XWUA5DX1201
120
2000 16.6 60 1 L5-20P
All ovens have two air heaters at 925 watts each.
Model CO151XWUA5D Series also has a water pan heater at 1850 watts.
All models are designed for AC Service. Model numbers may have the letters: B, L, M, S, T, U, or Z.
VENTING YOUR OVEN:
1. This cabinet passes the EPA 202 test and complies
with section 59 of UL710B for emission of grease-
laden air.
2. According to UL, this cabinet does not need to be
placed under a ventilation hood.
3. Installation must conform with local codes. The
authority having jurisdiction of enforcement of
the codes will have the responsibility for making
interpretations of the rules.
HOW TO INSTALL OVENS:
1. Remove all packing material from inside and outside
of oven.
2. Position oven on level oor; install the oven interior
(pan slides) if not already installed.
3. Plug power cord into proper wall receptacle.
LOW WATER LIGHT:
MANUAL FILL: When water needs to be added to the
pan, the Low Water Light will stay on and the humidity
will not work until the pan is relled.
AUTO FILL: If water level is low and water supply is not
connected, an error code will display after a time limit.
FIRST-TIME OPERATION
NOTE: A new oven needs to “burn off” manufacturing
oils and excessive adhesive before its rst use.
Do NOT load food into oven until this has been
done!
1. Push the switch to on; the light will come on.
NOTE: The letters “LOTPR” (low temperature) will show
on the control panel until it reaches 140°F (60°C).
2. Press the “COOK” button.
3. Push down and turn the control knob to show 200°F.
Push the knob again to set the temperature. Run the
unit for one (1) hour.
4. Turn the unit off and let cool.
5. Wipe the inside clean with detergent and hot water.
