5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Convection
Humidity Oven
FL-2373
Rev. 4 (6/15)
Page 3 of 14
HOW TO INSTALL CABINETS:
1. Remove all packing material from inside and outside
of cabinet.
2. Position cabinet on level oor; install the cabinet
interior (pan slides) if not already installed.
3. Plug power cord into proper wall receptacle.
4. MANUAL FILL: Fill water pan with three (3) gallons
of HOT water (see CAUTION).
5. AUTO FILL: Attach water valve on back bottom of
unit to water supply (see “How to use Automatic ll
kit on page 7).
LOW WATER LIGHT:
MANUAL FILL: When water needs to be added to the
pan, the Low Water Light will stay on and the humidity
function will not work until the pan is relled.
AUTO FILL: If water level is low and water supply is not
connected, an error code will display after a time limit.
INSTALLATION INSTRUCTIONS
VENTING YOUR OVEN:
1. The purpose of ventilating hoods is to direct and
capture smoke, grease-laden vapors, heat, odors, or
fumes.
2. Low temperature equipment (maximum temperature
250°F/121°C) does not produce heat, odors, fumes,
grease-laden vapors or smoke and is not required to be
vented.
3. Most jurisdictions consider our low-temperature ovens
(maximum temperature is 350°F/177°C) as low-heat
appliances not requiring vent hoods.
4. Installation must conform with local codes. The
authority having jurisdiction of enforcement of
the codes will have the responsibility for making
interpretations of the rules.
Use of treated water is recommended for
proper operation and to maintain warranty.
It will reduce scaling.
CAUTION
HOW TO CHANGE FROM °F TO °C (if needed)
1. Push the switch on; the light will come on.
2. Push and hold the “SET” button and the button in the
lower left hand corner together for 5 seconds.
You have now entered into the menu.
3. Scroll over the”Unit” and change it to “C” , then scroll
to the “END”.
UNIT SPECIFICATIONS: All units use three (3) elements (2670 watts each).
All units are rated 8000 watts. Water units have one (1) immersion element (1850 watts).
MODEL NOS.
ELECTRICAL SPECS
(AC SERVICE)
ELEC. LOAD
POWER SUPPLY REQUIREMENT
ALL 3 PHASE IS 3 WIRE + GROUND
CONVECTION OVENS Volts Ph Hz. Amps Volts Amps Ph Volts NEMA
CO151FWUA12DE2081
CO151FWUA12DE2401
208
240
1
1
60
60
39
34
208
240
50
50
1
1
208
240
6-50P
6-50P
CO151FWUA12DE2083
CO151FWUA12DE2403
208
240
3
3
60
60
23
20
208
240
30
30
3
3
208
240
L15-30P
L15-30P
HALF-SIZE OVENS
Are rated at 4700 watts (Three [3] heaters at 1470 watts each)
CO151HWUA6DE2081
CO151HWUA6DE2401
208
240
1
1
60
60
24
21
208
240
30
30
1
1
208
240
6-30P
6-30P
CO151HWUA6DE2083
CO151HWUA6DE2403
208
240
3
3
60
60
15
13
208
240
20
20
3
3
208
240
L15-20P
L15-20P
CO151XWUA5DE2081
CO151XWUA5DE2401
208
240
1
1
60
60
24
21
208
240
30
30
1
1
208
240
6-30P
6-30P
CO151XWUA5DE2083
CO151XWUA5DE2403
208
240
3
3
60
60
15
13
208
240
20
20
3
3
208
240
L15-20P
L15-20P
All models are designed for AC Service. Model numbers may have the letters: DX, P, L, M, Z or S.
