5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Convection Oven
FL-2368
Rev. 3 (2/15)
Page 3 of 13
INSTALLATION INSTRUCTIONS
UNIT SPECIFICATIONS: All units use six (6) elements (1325 watts each). All units are rated 8000 watts.
MODEL NOS.
ELECTRICAL SPECS
(AC SERVICE)
ELEC. LOAD
POWER SUPPLY REQUIREMENT
ALL 3 PHASE IS 3 WIRE + GROUND
CONVECTION OVENS Volts Ph Hz. Amps Volts Amps Ph Volts NEMA
CO151FUA12DE2081
CO151FUA12DE2401
208
240
1
1
60
60
39
34
208
240
50
50
1
1
208
240
6-50P
6-50P
CO151FUA12DE2083
CO151FUA12DE2403
208
240
3
3
60
60
23
20
208
240
30
30
3
3
208
240
L15-30P
L15-30P
CO151F1332DE2081
CO151F1332DE2401
208
240
1
1
60
60
39
34
208
240
50
50
1
1
208
240
6-50P
6-50P
CO151F1332DE2083
CO151F1332DE2403
208
240
3
3
60
60
23
20
208
240
30
30
3
3
208
240
L15-30P
L15-30P
CO151F1818DE2081
CO151F1818DE2401
208
240
1
1
60
60
39
34
208
240
50
50
1
1
208
240
6-50P
6-50P
CO151F1818DE2083
CO151F1818DE2403
208
240
3
3
60
60
23
20
208
240
30
30
3
3
208
240
L15-30P
L15-30P
All models are designed for AC Service. Model numbers may have the letters: DX, L, M, P, U, Z or S.
HOW TO INSTALL OVENS:
1. Remove all packing material from inside and outside
of oven.
2. Position oven on level oor; install the oven interior
(pan slides) if not already installed.
3. Plug power cord into proper wall receptacle.
VENTING YOUR OVEN:
1. This cabinet passes the EPA 202 test and complies
with section 59 of UL710B for emission of grease-
laden air.
2. According to UL, this cabinet does not need to be
placed under a ventilation hood.
3. Installation must conform with local codes. The
authority having jurisdiction of enforcement of
the codes will have the responsibility for making
interpretations of the rules.
FIRST-TIME OPERATION
NOTE: A new oven needs to “burn off” manufacturing
oils and excessive adhesive before its rst use. Do NOT
load food into oven until this has been done!
1. Push the switch to on; the light will come on.
NOTE: The letters “LOtPr” (low temperature) will show
on the control panel until it reaches 140°F (60°C).
2. Press the “COOK” button.
3. Turn the control knob to show 350°F. Push the knob 3
times to heat the unit. Run the unit like this for one
(1) hour.
4. Turn the unit off and let cool.
5. Wipe the inside clean with detergent and hot water.
HOW TO CHANGE FROM °F TO °C (if needed)
1. Push the switch on; the light will come on.
2. Push and hold the “SET” button and the button in the
lower left hand corner together for 5 seconds.
You have now entered into the menu.
3. Scroll over the”Unit” and change it to “C” , then scroll
to the “END”.
