Ovens
FL-2374-D
Rev. 3 (2/15) Page 3 of 13
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
5925 Heisley Road • Mentor, OH 44060-1833
INSTALLATION INSTRUCTIONS
SPECIFICATIONS: All units are rated 3000 watts/2650 watts at 208 Volts/240 Volts
CMP MODEL NOS.
ELECTRICAL SPECS
(AC SERVICE)
ELEC. LOAD POWER SUPPLY REQUIREMENT
SINGLE OVENS Volts Ph Hz. Amps Volts Amps Ph Wire Volts NEMA
500CHSSDE
500CHALDE
750CHSSDE
1000CHSSSPLITDE
208
240
208
240
1
1
1
1
60
60
60
60
14
11
14
13
208
240
208
240
20
20
20
20
1
1
1
1
2
2
2
2
208
240
208
240
6-20P
6-20P
6-20P
6-20P
500CHSSDE3
500CHALDE3
750CHSSDE3
1000CHSSSPLITDE3
208
240
208
240
3
3
3
3
60
60
60
60
8
7
8
7
208
240
208
240
20
20
20
20
3
3
3
3
3
3
3
3
208
240
208
240
L15-20P
L15-20P
L15-20P
L15-20P
SPECIFICATIONS: All units are rated 2000 watts.
CMP MODEL NOS.
ELECTRICAL SPECS
(AC SERVICE)
ELEC. LOAD POWER SUPPLY REQUIREMENT
SINGLE OVENS Volts Ph Hz. Amps Volts Amps Ph Wire Volts NEMA
500CHSSDE120
750CHSSDE120
1000CHSSSPLITDE120
120 1 60 16.6 120 20 1 2 120 5-20P
Model number “AL” is aluminum outer body with stainless steel doors and interior.
“DE” in model number will be substituted with “DX” for “Deluxe” Ovens.
All models designed for AC Service. Model number may include a variety of informational sufx letters.
NOTE: OVENS NEED TO BE INSTALLED BY A
QUALIFIED PERSON.
For models rated at 208/240 Volts:
Check the voltage selector switch which is under an access
cover on the back of the oven near the power cord.
Flip the switch “UP” for 208 Volts
Flip the switch “DOWN” for 240 Volts
MAKE SURE THE SWITCH POSITION MATCHES
YOUR POWER SOURCE.
VENTING YOUR OVEN:
1. This cabinet passes the EPA 202 test and complies
with section 59 of UL710B for emission of grease-
laden air.
2. According to UL, this cabinet does not need to be
placed under a ventilation hood.
3. Installation must conform with local codes. The
authority having jurisdiction of enforcement of
the codes will have the responsibility for making
interpretations of the rules.
