Ovens
FL-2340-D
Rev. 3 (2/15) Page 13 of 13
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
5925 Heisley Road • Mentor, OH 44060-1833
WIRING DIAGRAM FOR 1000-CH-D3
208/240 Volt, Three Phase
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
K3 K1 K2
RENAU CONTROL
BOTTOM CABINET
LOOKING AT REAR
t°t°
MEAT
PROBE
AIR
PROBE
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
K3 K1 K2
RENAU CONTROL
TOP CABINET
LOOKING AT REAR
t°t°
MEAT
PROBE
AIR
PROBE
POWER
SWITCH
(Upper Cabinet)
N
N
L
L
POWER
SWITCH
(Lower Cabinet)
N
N
L
L
TERMINAL
BLOCK
VENT
FAN
VENT
FAN
SECURE ALL WIRES
AWAY FROM FAN
BLADES
TRIAD
12
VAC
WHITE
BLACK
BLUE
BROWN
GRAY
YELLOW
PURPLE
RED
208/240
VAC
brown
blue
TRIAD
12
VAC
WHITE
BLACK
BLUE
BROWN
GRAY
YELLOW
PURPLE
RED
208/240
VAC
TERMINAL
BLOCK
UPPER CABINET
LOWER CABINET
FAN SWITCH
1
2
3
4
EXTERNAL ALARM
1
2
3
4
EXTERNAL ALARM
SOLID STATE RELAY
(Upper Cabinet)
L1 T1
A2(-) A1(+)
HIGH LIMIT
(Lower cabinet)
L1 T1
A2(-) A1(+)
SOLID STATE RELAY
(Lower Cabinet)
L1 T1
A2(-) A1(+)
L1 T1
A2(-) A1(+)
HIGH LIMIT
(Upper cabinet)
Upper
Cabinet
Heaters
Lower
Cabinet
Heaters
3A
3A
FUSES
GROUND*
POWER CORD
OPTIONAL
DELUXE
MODELS ONLY
OPTIONAL
DELUXE
MODELS ONLY
