25
Low lame
If burners do not light properly:
ig lame
MAX
MIN
a
OFF
b
a
b
ADJUST FLAME HEIGHT
Check and adjust the height of top burner flames. The cooktop "low" burner
flame should be a steady blue flame approximately 1/4" (6 mm) high. Propane
gas flames have a slightly yellow tip.
To adjust standard burner:
IMPORTANT: Adjustments must be made with two other burners in operation
on a medium setting. This prevents the upper row of flames from being set too
low, resulting in the flame being extinguished when other burners are turned
on.
The flame can be adjusted using the adjustment screw in the center of the
valve stem. The valve stem is located directly behind the control knob.
Adjustment screw
Control k
nob s
tem
1. Turn burner control knob to the "OFF" position.
2. Check that the cooktop is plugged in. Check that the circuit breaker has
not tripped or the household fuse has not blown.
3. Check that the gas shutoff valves are set to the "open" position.
4. Check that burner caps are properly positioned on burner bases.
1. Light the burner and turn the knob to the lowest setting (MIN).
2. Pull and remove the control knob.
3. Insert a small, flat-blade screwdriver into the adjustment screw, and
slowly turn the screw until the flame appearance is correct.
• Open the valve more if the flames are too small or fluttered.
• Close the valve more if the flames are too large.
4. Replace the control knob.
5. Test and check the flame by turning the control knob from the lowest to
the highest settings.
