CARBIDE SERIES

SPEC-06

ENGLISH

Table of contents Case speciﬁcations

Case specications ........................................................................................................................................................2

Accessory kit contents ..................................................................................................................................................3

Case features ..................................................................................................................................................................4

Removing the side panels ..............................................................................................................................................5

Installing the motherboard ............................................................................................................................................6

Installing HDDs ...............................................................................................................................................................7

Installing SSDs ................................................................................................................................................................8

Installing PSU .................................................................................................................................................................. 9

Installing PCI-e card(s) .................................................................................................................................................10

Removing the front bezel .............................................................................................................................................11

Installing the front I/O connectors ..............................................................................................................................12

Using RGB fan controller .............................................................................................................................................12

Frequently asked questions ........................................................................................................................................13

215mm

474mm

455mm

Fan locations

Front ..............................................3 x 120mm / 2 x 140mm

Top ................................................2 x 120mm / 1 x 140mm

Rear .......................................................................... 120mm

Radiator compatibility

Front .......................................... 360mm / 280mm / 240mm

Top ...........................................................................240mm

Rear .......................................................................... 120mm

Length .................................................................... 474mm

Width ....................................................................... 215mm

Height ..................................................................... 455mm

Maximum GPU length ......................................... 370mm

Maximum CPU height ......................................... 170mm

Maximum PSU length ......................................... 180mm
