24
(3) . Installation
● Clamps and hooks for installation
inner chimney holder
outer chimney holder
Wall hook
(3). Installation
Island hood:
3 . 1 Make sure of installation position, fix the hanging scaffold at proper position, and check firmness and
smoothness of installation. See the pic 1 .
3 . 2 Adjust to proper height, joint the bracket, install on hanging scaffold. See the pic 2 .
3 . 3 Fix inside chimney on hanging scaffold, enclose outside chimney on it at proper position, insert hook
into bracket to fix outside chimney temporarily. See the pic 3 .
3 . 4 Fix air outlet in the vent on hood’ s body, connect extensible pipe with air outlet. See the pic 4 .
3 . 5 Extend the hose out off hanging scaffold, fix hood’ s body on bracket. See the pic5 .
3.6 Detach the hook, move outside chimney downward till reaching hood’s body. Pay attention not to strike
the glass. See the pic 6.
