9. Place the lower door on a smooth
surface with its panel upwards.
Loose screw and take down part
and part , Install replacement
door stopper-left provided (in the
plastic bag) and part (stop block)
to the left side with screw . Keep
part with the appliance for future
reference.
10. Change screw hole covers on
middle cover plate from left to right
(as shown in figure below).
③
②
②
③
11. Tip the refrigerator backwards,
remove part
①
①
②.
④
12.
13.
14.
15.
Remove part from the lower
hinge pin, loose out the lower hinge
pin, change it to the reverse hole
site, and then tighten into position,
then install part on the lower
hinge pin.
Slot the lower door onto the
bottom hinge pin and hold in
position. Turn the middle hinge by
180°, change the washer on the axis
to the lower side, adjust the middle
hinge to the appropriate position and
then install it ensuring the lower
door in secured place.
Move the upper door to an
appropriate position, and then fix
③
①
④.
②
③
Replacetheitemsremountin
step11,changepart toleft and
thenfixthemwithscrews Install
part atlast.
,
Lower hinge part (left)
① Lower hinge part (right)
Adjustable bottom feet part
Adjustable bottom feet part
Self-tapping screws
Adjustable bottom feet part
②
③
④
⑤
①
②
③
④
⑤
Note: washer may
stick to lower door.
Washer
④
