6
REFRIGERATED BASES & PIZZA PREP TABLES
OPERATIONS MANUAL
INSTALLING LEGS AND LEVELING
If your new unit is supplied with adjustable legs, they will be
packed in the accessory carton in the cabinet. Your cabinet will
have either four (4) or (6) threaded mounting holes on the bot-
tom of the cabinet (see Figure 4). In order to install the legs,
carefully tip the cabinet back, adding four (4) 2” wood blocks
underneath, and simply screw the threaded leg studs into the
case bottom front leg holes. Repeat this procedure by tilting the
cabinet in the opposite direction and install the remaining legs.
Make sure the legs are tightened extremely well or the entire
model will sway or rock with each opening or closing of the
doors, possibly causing damage to the case bottom. This pro-
cedure should be performed close to the final installation site.
To assure your cabinet is level, all legs are equipped with bullet-
type leveling bolts. These bolts can be turned by hand or by
wrench, clockwise or counterclockwise to level the cabinet.
CONDENSATE REMOVAL
All models utilize a unique hot air condensate water evaporat-
ing system which is completely self-contained and no further
assembly or maintenance is required (see Figure 5 & 5A). In
some adverse conditions such as high ambient temperature,
high humidity, extremely heavy usage, frequent loading for
prolonged periods of time, or heavy pan loading, the amount
of condensate water generated could overflow the pan. If
this occurs, the plastic drain tube from the cabinet can be
diverted directly to a floor drain, bypassing the condensate pan.
Alternatively, an optional electric condensate heater may be pur-
chased as an accessory. An electric condensate heater is also
supplied with all remote models. To install the electric heater,
see “Installing Electric Condensate Heater” in the “Optional
Accessories” section at the back of this manual.
FIGURE 4: Leg Installation
FIGURE 5: CRB Components (Rear View)
A
LEG
LEG INSTALLATION
BLOCKS
THREADED
END
TURN FOOT CLOCKWISE
TO REDUCE HEIGHT, OR
COUNTERCLOCKWISE
TO INCREASE HEIGHT.
CPT/CFB/CRB BACK COVER REMOVED
REMOVE SCREWS FROM
TOP OF BACK PANEL AND
LIFT OFF TO REMOVE
DRAIN PAN
DRAIN LINE
DEFROST TIMER
(FREEZERS ONLY)
FIGURE 5A: CPA/CRA Components (Rear View)
DRAIN PAN
REMOVE SCREWS FROM
ACCESS PANEL AND
LIFT OFF TO REMOVE.
DRAIN
LINE
CPA CONDENSATE PAN ACCESS
