4
REFRIGERATED BASES & PIZZA PREP TABLES
OPERATIONS MANUAL
FIGURE 2: Minimum Clearance Dimensions for Optimum Conditions (Except for Undercounter & Front Breathing Models)
IMPORTANT NOTE: Do not under any circumstances, lay
your new model on its front or sides. For a brief period of
time, you may lay the cabinet on its back, but only when
it’s properly blocked so as not to crush the louvered
venting panel and also to allow provision for your hands,
in order to set it in its upright position without damaging
the cabinet. Do not plug in and operate model for at
least three (3) hours after cabinet is set upright from
being on its back as this can damage the compressor.
INSTALLATION AND LOCATION
Before moving the cabinet to its final point of installation, mea-
sure all doorways or passages to assure clearance. If additional
clearance is needed, you can remove the cabinet doors (see
“Removal of Doors and Door Adjustment”) and lids (when
equipped) (see “Removing Lid and Hood”).
VENTILATION
The final location site of your air cooled refrigerator or freezer
must provide a large quantity of cool, clean air. All refrigeration
systems operate most efficiently and trouble-free with cool,
dry air circulation. Avoid locations near heat and moisture
generating equipment including ovens, cooking ranges, fryers,
dishwashers, steam kettles, etc., or in direct sunlight (where
temperatures can exceed 100°F). Do not select a location in an
unheated room or area where temperatures may drop below
55°F. Air supply to the condensing unit is equally important—
restricting the air flow will result in excessive heat load on the
condensing unit and adversely affect its operation.
NOTE: Heat-generating equipment (griddles, broilers,
toasters, etc.) should have a minimum 4” clearance
underneath, to the top of your refrigerated cabinet.
Temperature at cabinet surface should not exceed 100°F,
or damage can occur to your cabinet which is not covered
under warranty. If needed, a heat shield must be used to
protect your cabinet.
For optimum performance, all models (except for Undercounters
and Front Breathing cabinets) should be installed on casters or
legs (see “Installing Casters” or Installing Legs”) with a mini-
mum 3” clearance on each side and the back of the cabinet (see
Figure 2). If any of the above conditions can not be achieved, the
installer should provide special venting or air supply ducts, or a
Front-Breather Kit (see “Optional Accessories”) can be ordered
by contacting the factory.
Undercounter and Front Breathing models do not require any
clearance around the sides or back of the cabinet, since they take
in and exhaust air under the cabinet and through the front grill,
under the door. The air flow under the cabinet and through the
front grill must not be restricted.
IMPORTANT NOTE: For optimum performance, your
cabinet should be located where an unrestricted air sup-
ply can circulate underneath and behind the cabinet. Do
not obstruct the grill in the rear of the cabinet in any way,
and never place or store anything inside the compressor
compartment. These rules are essential for maximum
cooling capacity and long life of your unit.
