10
REFRIGERATED BASES & PIZZA PREP TABLES
OPERATIONS MANUAL
115 VOLT, 60 HZ, 1 PHASE CONNECTION
All 115 volt models are provided with
a factory installed, UL approved power
cord and polarized plug. To insure proper
operation, this equipment must be plugged
into a NEMA 5-15r compatible, grounded
receptacle that can supply the full voltage
as stated on the serial data plate.
Some 115 volt models (including CPA118)
require 20 amp supply power and must be
plugged into a NEMA 5-20R receptacle.
WARNING: ANY ALTERATIONS TO THIS CORD AND
PLUG COULD CAUSE AN ELECTRICAL HAZARD AND
WILL VOID THE FACTORY WARRANTY.
SPECIAL VOLTAGE CONNECTIONS
When models are ordered from the factory with special, optional
voltages, connections should be made as required on the electri-
cal wiring diagram provided on the inside compressor compart-
ment rear next to the electrical console box.
START-UP CHECKLIST
After your unit has been installed and electrically connected in
accordance with this manual, please take time to check the fol-
lowing before loading product, to assure trouble free operation:
Sufficient clearance provided (see “Ventilation”)
Separate supply with correct voltage
(see “Electrical Connections”)
Cabinet level and casters/legs tight
(see “Installation and Location”)
Doors close and seal properly
(see “Door Removal and Adjustment”)
Correct cabinet temperature
(see “System and Adjustment”)
Thermometer calibrated (see “Thermometer”)
Refrigeration lines free of kinks and vibration
(see “Refrigeration System”)
All fans rotate freely (see “Refrigeration System”)
Freezers only: defrost clock set
(see “Freezer System and Adjustment”)
Pilaster clips secure and shelves level
(see “Shelving Installation”)
Pizza & Sandwich: All pans and dividers in place
(see “Pizza Prep and Sandwich Top Pan Openings”)
All packaging discarded and cabinet cleaned
(see “Periodic Cleaning”)
09/03/10
INITIAL CLEANING PROCEDURE
Prior to start-up and before placing any product inside of your
new model, the interior of the cabinet should be thoroughly
cleaned. Washing with a mild soap and warm water solution
is recommended for cleaning the aluminum and stainless steel
surfaces of your cabinet. This should be followed by cleaning
with a baking soda solution (three (3) tablespoons of baking
soda to each quart of warm water). Rinse thoroughly with clear
water and dry with a clean, soft cloth.
IMPORTANT NOTE: Never use harsh detergents, clean-
ers, scouring powders or chemicals when cleaning your
model. Failure to dry the interior surfaces after cleaning
may result in a streaking or staining of the metal.
Complete cleaning procedures and precautions are listed in the
(“Periodic Cleaning Procedure” under “Maintenance”).
START-UP PROCEDURE
ELECTRICAL CONNECTIONS
To insure proper operation, your new model must be connected
to an individual circuit that can supply the full voltage as stated
on the cabinet serial data plate. For correct voltage, power draw,
and wire accommodations, check the data on the serial data
plate located on the inner right wall of your new model. Verify
that this information exactly matches the electrical character-
istics at the installation location. An electrical wiring diagram,
located on the inside compressor compartment rear, next to
the electrical console box, should also be consulted during
connection. For reference, a copy of each electrical wiring dia-
gram is located towards the back of this manual (see “Wiring
Diagrams” section).
IMPORTANT NOTE: The condensing unit supplied with
all self-contained models is designed to operate within a
range of +/-10% of the voltage indicated on the cabinet
serial data plate. Full voltage of the correct rating, on an
isolated line, not affected by the operation of other electri-
cal appliances, must be available to the refrigeration unit
at all times. Burnout of the compressor due to exceeding
high or low voltage limits is easily detected and will void
the factory warranty.
