en Installation instructions
76
To ventilate the appliance, the intermediate floor must
have a ventilation cut-out.
The worktop must be secured to the fitted unit.
Observe any available installation instructions for the
hob.
Observe different national installation instructions for
the hob.
In order to ensure sufficient ventilation of the appliance,
there must be a ventilation opening of at least
100cm². For example, trim the base panel or fit a vent-
ilation grille.
18.8 Installing below a hob
If the appliance is installed below a hob, the following
minimum dimensions must be adhered to (including
substructure, if applicable).
The minimum worktop thickness is based on the re-
quired minimum clearance .
Hob type raised in
mm
flush in
mm
in
mm
Induction hob 45 46 5
Full-surface in-
duction hob
55 56 5
Gas hob 35 46 5
1
Electric hob 35 38 2
1
Observe different national installation instructions
for the hob.
Observe the installation instructions for the hob.
18.9 Corner installation
Observe the installation dimensions and the safety
clearances when installing in a corner.
18.10 Installing the appliance
1.
Centre the appliance.
2.
Screw the appliance onto the unit.
18.11 For handleless kitchens with vertical
bar handle strips:
1.
Attach a suitable filling piece on both sides in order
to cover any sharp edges and to guarantee safe in-
stallation.
2.
Secure the filling piece to the unit.
