ACKNOWLEDGEMENTS
Thank you for purchasing aConcept product. We wish you much joy with your new appliance every day you use it.
Please read the instruction manual carefully before initial use. To refer to this manual any time you need to, we
recommend you to keep it in asafe place. And please pass it to any future owner of the appliance.
TABLE OF CONTENTS
Acknowledgements
Technical specications
Important safety information
Product description
Control panel layout
Examples of cooking application
Cooking tips
Energy saving tips
Operating instructions
Advanced features
Care and cleaning
Installation instructions
Troubleshooting
Error message
Environmental concerns
TECHNICAL SPECIFICATIONS
Voltage
220–240 V ~ 50 - 60 Hz
380-415 V ~ 50 - 60 Hz
Max. input power 5500 - 6600 W
Front cooking zone diameter and input ø 200 mm, 1 800 W
Rear cooking zone diameter and input ø165 mm, 1 200 W
Right front cooking zone diameter and input ø200 mm, 1 800 W
Right rear cooking zone diameter and input ø165 mm, 1 200 W
External dimensions (WxDxH) 590 x 520 x 51 mm
Dimensions for installation (WxDxH) 560 x480 x51 mm
Weight 7,2 kg
The manufacturer reserves the right to make any technical changes, printing errors and dierences in the illustration
without prior notice.
IMPORTANT SAFETY INFORMATION
Delivery
• Check the package and unit immediately after the delivery for any damage
that may have occurred during shipping.
• CAUTION! Some corners and edges of this appliance that will be hidden after
installation can be sharp! Take care to avoid injury!
• If the unit is damaged, do not operate it. Contact the supplier as soon as
possible.
• Remove all the covering and marketing materials from the appliance before
the rst use.
• Keep all packaging away from children and dispose of it appropriately.
y This appliance must be installed in accordance with the regulations
in force and should only be used in a well-ventilated area. Read the
manuals before installing and using the appliance.
Installation
• The appliance is intended for assembly into correct built-in units and
workspaces that align to the standards.
• The sealant on the edges of the appliance protects the cut surfaces of the
worktop against moisture.
• Use the unit only as described in this instruction manual.
• The appliance has to be disconnected from the power supply during
installation.
• Make sure that the parameters on the rating plate are compatible with the
electrical ratings of the main power supply. Use only correct electricity mains
cable that is earthed.
• This appliance can be used in households and similar areas such as:
• Kitchen areas in shops, oces and other workplaces.
• Appliances used in agriculture.
• Appliances used by guests in hotels and other areas in ahotel environment.
• Appliances used in aBed and Breakfast environment.
• Make sure the mains cables of other electrical appliances do not touch the hot
cooking zones. Otherwise both the insulation of the cables and the hob may
be damaged.
• Never touch hot cooking zones. Risk of burns!
• The indicator of residual heat “H” shows that the cooking zones are still hot.
Keep children away from the appliance. Risk of serious burns!
