64 65
ENEN
PRODUCT DESCRIPTION
A Refrigerator
B Freezer
1 Control panel with display
2 Lightwall lighting on all shelves
3 Door shelves
4 Shelves in the refrigerator
5 Folding wine shelf
6 Bottle shelf
7 Fruit and vegetable drawer
8 Drawer for meat and sh
9 Drawers in the freezer
CONTROL PANEL DESCRIPTION
1 Temperature setting button in the chiller (bottom drawer in the refrigerator)
2 Super cool function button
3 Holiday function button
4 Refrigerator temperature setting button
5 Display - refrigerator temperature display
6 Display - freezer temperature display
7 Freezer temperature setting button
8 Eco function button
9 Super freeze function button
10 O and on button
1 2 3 4 7 8 9 105 6
1
3
6
5
2
7
8
9
4
B
A
APPLIANCE DIMENSIONS
APPLIANCE INSTALLATION
• CAUTION! Some corners and edges of the appliance that will be hidden after installation may be sharp!
Take care to avoid injury!
• Defects caused by incorrect installation are not covered by the warranty.
• It is the responsibility of the purchaser, not the manufacturer, to install the appliance.
• The manufacturer shall not be liable in any way for damage to persons, animals or property caused by improper
installation.
• Place the appliance in a level place in a well-ventilated room, at a safe distance from heat sources (radiators, ovens).
• Avoid placing the appliance in a place of direct sunlight, humid environment.
• Do not tilt the appliance more than 40°.
• If necessary, use the adjustable feet at the bottom of the appliance to level the appliance to a stable and horizontal
position.
• For ventilation reasons, the appliance must not touch the wall at the back, the bigger the gap the better.
There should also be a clear space at the top and a cut-out (with a ventilation grille) in the plinth under the fridge.
• Improper ventilation can lead to e.g. premature compressor failure, excessive energy consumption.
1778 - 1781
661
556
min. 565
min. 560
min. 40
550
200 cm
3
A
A
1003
14
200 cm
3
