6 /9

6. API Commands

This product supports API commands control. Connect the SERVICE or RS-232 port of the

product to a PC, then open a Serial Command tool on PC to send ASCII commands to

control the product. The API commands list is shown below.

ASCII Commands

1. Service port (USB-C virtual RS-232) communication protocol (Internal debug)

Baud rate: 115200(Fixed) Data bit: 8 Stop bit: 1 Parity bit: none

The end mark of command is “<CR><LF>”

2. Phoenix RS-232 port communication protocol (Connect to control system)

Baud rate: 4800~115200(Configurable) Data bit: 8 Stop bit: 1 Parity bit: none

The end mark of command is “<CR><LF>”

Command

Function Example Feedback

Default

?

Get the list of all commands

?

help

Get the list of all commands

help

get fw version Get firmware version

get fw version

1.0.0

set reboot

Reboot the device

set reboot

Reboot…

System Initializing...

Initialization Finished!

FW: 1.0.0

set reset

Reset to factory defaults

set reset

Sure to RESET to

default settings? Type

"Yes" after next

prompt to confirm…

get status

Get system status

get status

Please refer to the note

at the end of the list.

set key on/off

Set front panel key on/off

set key on

set key off

Set key on

Set key off

on

get key

Get front panel key on/off status

get key

Key on

set baud x

Set RS-232 baud rate to x bps

x=1: 4800

x=2: 9600

x=3: 19200

x=4: 38400

x=5: 57600

x=6: 115200

set baud 6

Set baud rate 115200

115200

get baud

Get RS-232 baud rate

get baud

Baud rate 115200
