Push the Exhaust hose into the airoutlet opening
of the unit along the arrow direction.
4
Hung Window Installation
Step 1: Insert the window slider assembly into the window opening.
Step 2: Cut the non-adhesive foam seal C strip to match the width of the window. Insert the seal
between the glass and the window frame to prevent air and insects from getting into the room.
Step 3: If desired, install the security bracket with 2 screws as shown.
5
Sliding Window Installation
6
Install the Exhaust hose assembly
to the unit
Insert the window slider adaptor into the hole of
the window slider.
7
Connect the adaptor to the unit
and the window
Step 1: Insert the window slider assembly into the window opening.
Step 2: Cut the non-adhesive foam seal C strip to match the height of the window. Insert the seal
between the glass and the window frame to prevent air and insects from getting into the room.
Step 3: If desired, install the security bracket with 2 screws as shown.
NOTE:
Once the Exhaust Hose assembly and Adjustable Window Slider are
prepared, choose from one of the following two installation methods.
NOTE:
Once the Exhaust Hose assembly and Adjustable Window Slider are
prepared, choose from one of the following two installation methods.
Hung Window Installation Sliding Window Installation
20
