Collomix GmbH TMX 1000
85080 Gaimersheim TMX 1500
19
Funconality
The machine consists of a mobile frame with a permanently mounted mixing bucket made of
steel sheet. A 3-arm mixing tool rotates in the mixing drum around a central drive axis.
Ideally, the mixer is rst lled with the dry material and then the necessary amount of water is
added to the running machine
The materials are usually mixed and ready for use within three to ve minutes. Observe the
informaon of the material manufacturer and check the mixing quality using a test mixture.
Open the segment slidegate at the boom of the bucket to empty the mixer during operaon.
The rotang mixing tool conveys the material to the discharge chute.
Transport informaon
The machine is delivered on a pallet without wheels. Observe the assembly instrucons.
The empty weight of the machine amounts to 131 kg (TMX 1000) /138 kg (TMX 1500).
ATTENTION!
The machine must always be suciently secured against lng and rolling away using several
transport straps for vehicle transport. Non-secured loads can result in serious personal injury
and material damage.
Lash the machine via the lashing eyes with lashing strips of a sucient size.
The lashing eyes are not suitable for transportaon by crane.
Assembly
The following tools are required for inial assembly:
1 x open-end wrench SW 10; 2 x open-end wrench SW 17
Removal of the transport lock:
Loosen the screw connecons of the four feet on the pallet. (Open-end wrench SW 10 )
Adjusng the height:
ATTENTION!
Risk of pping! Seek the assistance of a second person in this regard.
Loosen the 4 screws on the two front feet using two open-end wrenches SW 17. Tilt the machine
unl it becomes possible to insert the 4 screws into the upper bores. Then ghten the screws
again.
EN
