The following START-UP SUMMARY is for quick reference ONLY. For safe operation and use of this
equipment, the operators should comply with all safety and operating instructions in this manual.
Lighting Instructions
1. Turn the ON/OFF lever/switch to the ON position.
•
Blower will start and boiler will fill with water (about 3 minutes).
•
Pilot will attempt to light for 90 seconds.
•
If no ignition occurs the system will automatically reset in 6-7 minutes.
2. System may be reset manually by turning the ON/OFF lever/switch to the OFF position for 5 minutes
and then back to ON.
3. Turn ON a cooking compartment.
4. Blower will start and main burner will light.
5. Each compartment has its own control system, and must be started independently.
Shutdown Instructions
Turn the ON/OFF lever/switch to the OFF position. The burners and pilots will immediately be
extinguished and the unit will begin the automatic 3-minute blowdown cycle and drain. NOTE: Each
compartment has its own control system, and must be shut off independently.
E. INSPECTING THE COOKING COMPARTMENT
At the back of the cooking compartment, a drain screen covers the drain (Refer to Figure3-2). The screen
prevents large food particles from entering and blocking the drain line. Any blockage of the drain line or
screen can reduce drainage from the cooking compartment resulting in reduced cooking performance,
equipment damage, and a hazard to the operator. A blocked or slow drain may cause:
•
Hot water to collect in the compartment and
spill out when the compartment door opens.
•
Pressure fluctuations in the compartment,
resulting in steam leaks around the door
gasket, or compartment implosion.
•
Reduced convection in the compartment,
reducing cooking performance.
Figure 3-2 Compartment
Drain Screen
DRAIN SCREEN
WARNING
DEATH, INJURY OR EQUIPMENT DAMAGE may result from an
improperly adjusted gas control and ignition system. Do not alter any
adjustments on this electronic control or gas valve.
If adjustment is required, contact an authorized service center. Cleveland
Range is in no way responsible for the operation or safety of this
equipment if the controller, valve, or igniter probe are adjusted by anyone
other than a Cleveland Range authorized service representative.
