Page 11
PL70EN-B4
03/10/2014
EN
Description
1 RS196 1 2 Ball Bearing
2 Table "C" 1 Gear Cage
3 9D7890 2 4 Planetary Gear Pin
4 Table "C" 2 4 Planetary Gear (includes Ref. 5)
5 16113 2 4 Planetary Gear Needle Bearing
6 Table "C" 1 2 Pinion Gear
7 9D7892 1 Ring Gear
8 80G216 1 2 Ring Gear Pin
9 12686 1 2 Washer
10 9D7908 1 3 Center Housing Gasket
1 1 30078PT 1 Center Housing
12 30775PT 2 2 Flush Type Grease Fitting
13 B115M 6 6 Socket Head Cap Screw
14 525424 1 2 Ball Bearing
15 Table "C" 1 Gear Cage Output Spindle
16 10032 2 4 Planetary Gear Pin
17 Table "C" 2 4 Planetary Gear (includes Ref. 18)
18 Table "C" 2 4 Planetary Gear Needle Bearing
19 Table "C" 1 2 Pinion Gear
20 Table "C" 1 3 Output Spindle Key
21 18304 1 2 Ball Bearing
22 10019 1 Ring Gear
23 DP120PT 1 2 Ring Gear Pin
24 29719PT 1 3 Front Housing Gasket
25 29715PT 1 Front Housing
26 18307 1 3 Oil Seal
27 B117B 6 6 Socket Head Cap Screw
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "C": Double Stage Gearing Assembly
Ref
Number
#
X
Cleco
®
Double Stage Gearing
Table "C"
Ref. Description # B4R317M # B4R320M # B4R322M # B4R322M-NS # B4R323M
2 Gear Cage 1 507313 1 30079PT 1 30080PT 1 30080PT 1 30079PT
4 Planetary Gear 2 A9D7891(24T) 2 A18301(19T) 2 A9D7891(24T) 2 A9D7891(24T) 2 A18301(19T)
6 Pinion Gear --- 1 18312 ---- ---- 1 18312
15 Gear Cage Output Spindle 1 544122PT 1 544121PT 1 544121PT 1 A29720 1 544122PT
17 Planetary Gear 2 540766(19T) 2 A18322(4T) 2 A18322(4T) 2 A18322(4T) 2 540766(19T)
18 Planetary Gear Bearing 2 845845 2 21155 2 21155 2 21155 2 845845
19 Pinion Gear --- 1 18323 1 18323 1 18323 ----
20 Output Spindle Key 1 18308 1 18308 1 18308 1 29716PT 1 18308
(T) Teeth
