PL70EN-B4
03/10/2014
Page 7
EN
Description
-- 507489 1 Power Unit (includes Ref. 1-22)
1 C109C 5 10 Head Assembly Nut
2 A17740 1 Head Assembly (includes Ref. 3-5)
3 17747 1 1 Reducer Bushing
4 B112E 2 2 Pipe Plug
5 1VR77 1 1 Bushing
6 10100 1 Distributor
7 1V189 1 3 Head Gasket
8 A21385 1 Cylinder (includes Ref. 10)
9 9D7916 1 3 Cylinder Gasket
10 535712 1 2 Needle Bearing
1 1 213772PT 1 1 Bevel Gear
-- 511503 1 Socket Plate Assembly (includes Ref. 12-14)
12 511504 5 5 Piston Assembly
13 B122R 10 10 Screw
14 511505 1 Socket Plate
15 500740 1 3 Retaining Ring
16 22655 1 2 Duplex Bearing
17 511511 1 Driveshaft
18 1V155 1 2 Ball Bearing
19 520293 1 Rear Housing (includes Ref. 20-21)
20 22761 1 1 Bearing Liner
21 520294 4 4 Stud
22 30775PT 1 1 Flush Type Grease Fitting
23 530322 1 Nameplate (not included in 507488 power unit)
24 1443700 2 Drive Screw (not included in 507488 power unit)
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "A": Power Unit
Ref
Number
#
X
Cleco
®
Power Unit
