PL70-A8-EN
03/03/2017
EN
Description
1 525424 1 2 Ball Bearing
2 Table "D" 1 Gear Cage
3 10032 2 4 Planetary Gear Pin
4 Table "D" 2 4 Planetary Gear (includes Ref. 5)
5 Table "D" 2 4 Planetary Gear Needle Bearing (Bushing)
6 Table "D" 1 2 Pinion Gear
7 30075 1 2 Ball Bearing
8 10019 1 Ring Gear
9 DP120PT 1 2 Ring Gear Pin
10 10010 1 3 Center Housing Gasket
11 30050 1 Center Housing
12 30775PT 2 2 Flush Type Grease Fitting
13 B127D 12 12 Socket Head Cap Screw (5/16-18 x 3)
14 30076PT 1 2 Ball Bearing
15 Table "D" 1 Output Gear Cage
16 30058PT 2 4 Planetary Gear Pin
17 Table "D" 2 4 Planetary Gear (includes Ref. 18)
18 11700 4 8 Planetary Gear Needle Bearing
19 30063PT 1 2 Ball Bearing
20 30056PT 1 Ring Gear
21 30049 1 Front Housing
22 30057PT 1 3 Oil Seal
23 30072PT 1 3 Output Gear Cage Key
24 30053PT 1 Output Spindle
25 30071PT 1 3 Output Spindle Key
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "D": Double Stage Gearing Assembly
Ref Number # X
Table "D"
Ref. Description # A8R336M # A8R337M # A8R338M
2 Gear Cage 1 30060 1 30052PT 1 30739PT
4 Planetary Gear 2 540766 (19T) 2 A18322 (14T) 2 540766 (19T)
5 Needle Bearing (Bushing) 4 845845 4 21155 4 845845
6 Pinion Gear ---- 1 18323 ----
15 Gear Cage Output Spindle 1 30059 1 30051 1 30051
17 Planetary Gear 2 A30061 (21T) 2 A30055 (16T) 2 A30055 (16T)
(T) Teeth
Spare Parts
