Page 9
PL70-A8-EN
03/03/2017
EN
Description
1 525424 1 2 Ball Bearing
2 Table "B" 1 Gear Cage Output Spindle
3 10032 2 4 Planetary Gear Pin
4 18324 1 Drive Block
5 18320 1 Locating Ring
6 Table "B" 2 4 Planetary Gear (includes Ref. 7)
7 Table "B" 2 4 Planetary Gear Needle Bearing (Bushing)
8 Table "B" 1 2 Pinion Gear
9 10019 1 Ring Gear
10 DP120PT 1 2 Ring Gear Pin
11 18304 1 2 Ball Bearing
12 18307 1 3 Oil Seal
13 10010 1 3 Front Housing Gasket
14 18313 1 Front Housing
15 30775PT 1 1 Flush Type Grease Fitting
16 B119S 6 6 Socket Head Cap Screw (5/16-18 x 2-1/2)
17 18326 1 3 Output Spindle Key
(#) Quantity
(X) Recommended Spare Parts (quantity shown based on 1-5 tools in operation)
Illustration "B": Direct Drive and Single Stage Gearing Assemblies
Ref Number # X
Table "B"
Ref. Description # A8R309M # A8R310M # A8R311M
2 Gear Cage Output Spindle 1 544039 1 544039 1 544024
6 Planetary Gear ---- 2 A18322 (14T) 2 540766 (19T)
7 Needle Bearing (Bushing) ---- 2 21155 2 845845
8 Pinion Gear ---- 1 18323 ----
(T) Teeth
Spare Parts
