Page 20
45-8062EN
07/10/2013
Cleco
®
22 Series Rotary Vane Motors
11 Technical data
11.1 22 Series Specications
@ Max. HP Free Speed ft. lbs. Nm lbs. kg in. mm cfm m3/min
22-5000 215 430 41.2 55.83 4.2 1.91 7.94 202 29 0.82 50.4:1 Side
22-5040 215 430 41.2 55.83 4.1 1.86 7.94 202 29 0.82 50.4:1 Rear
22-5001 320 640 28.4 38.48 4.2 1.91 7.94 202 29 0.82 34.8:1 Side
22-5041 320 640 28.4 38.48 4.1 1.86 7.94 202 29 0.82 34.8:1 Rear
22-5002 470 940 19.6 26.56 4.2 1.91 7.94 202 29 0.82 24:1 Side
22-5042 470 940 19.6 26.56 4.1 1.86 7.94 202 29 0.82 24:1 Rear
22D5000-50 215 430 41.2 55.83 4.2 1.91 7.94 202 29 0.82 50.4:1 Side
22D5040-50 215 430 41.2 55.83 4.1 1.86 7.94 202 29 0.82 50.4:1 Rear
22D5001-50 320 640 28.4 38.48 4.2 1.91 7.94 202 29 0.82 34.8:1 Side
22D5041-50 320 640 28.4 38.48 4.1 1.86 7.94 202 29 0.82 34.8:1 Rear
22D5002-50 470 940 19.6 26.56 4.2 1.91 7.94 202 29 0.82 24:1 Side
22D5042-50 470 940 19.6 26.56 4.1 1.86 7.94 202 29 0.82 24:1 Rear
22M5000 215 430 41.2 55.83 5.1 2.31 7.94 202 29 0.82 50.4:1 Side
22M5040 215 430 41.2 55.83 5.0 2.27 7.94 202 29 0.82 50.4:1 Rear
22M5001 320 640 28.4 38.48 5.1 2.31 7.94 202 29 0.82 34.8:1 Side
22M5041 320 640 28.4 38.48 5.0 2.27 7.94 202 29 0.82 34.8:1 Rear
22M5002 470 940 19.6 26.56 5.1 2.31 7.94 202 29 0.82 24:1 Side
22M5042 470 940 19.6 26.56 5.0 2.27 7.94 202 29 0.82 24:1 Rear
22V5000-50 215 430 41.2 55.83 5.1 2.31 7.94 202 29 0.82 50.4:1 Side
22V5040-50 215 430 41.2 55.83 5.0 2.27 7.94 202 29 0.82 50.4:1 Rear
22V5001-50 320 640 28.4 38.48 5.1 2.31 7.94 202 29 0.82 34.8:1 Side
22V5041-50 320 640 28.4 38.48 5.0 2.27 7.94 202 29 0.82 34.8:1 Rear
22V5002-50 470 940 19.6 26.56 5.1 2.31 7.94 202 29 0.82 24:1 Side
22V5042-50 470 940 19.6 26.56 5.0 2.27 7.94 202 29 0.82 24:1 Rear
-01 Series 200 Collet Chuck (for milling and routing)
-38 0"-1/4" Capacity Drill Chuck
-50 1/2" Diameter Keyed Spindle
-51 1/16"-3/8" Capacity Drill Chuck
-53 5/64"-1/2" Capacity Drill Chuck
-62
Series "K" Collet Chuck (for milling and routing)
-63
4" x 1" x .50" Polishing Wheels
-64
8" x 1" x .62" Polishing Wheels
Flange and Base Mounting - Right Hand Rotation - See Termination Options
Flange and Base Mounting - Left Hand Rotation - 1/2" Diameter Keyed Spindle (only)
Termination Options for Right Hand Rotation Models:
Round Housing - Right Hand Rotation - See Termination Options
Air
Consumption
Model
Number
Stall
Torque
Weight
Maximum Allowable
RPM
Gear
Ratio
Exhaust
Overall Length
Round Housing - Left Hand Rotation - 1/2" Diameter Keyed Spindle (only)
