66
Device Name
Enter a descriptive name in the Device Name field. Device names are used as network identifier on NetBIOS
networks. They must start with a letter and can contain both letters and numbers, with a maximum length of 15
characters. No special characters are allowed except for “-”.
Device ID
Select a Device ID from the Device ID drop-down list.
Device IDs ensure that Console synchronizes with the proper unit when there are multiple units of the same type in
a site. Therefore, each unit of the same type in a site must have a unique Device ID assigned using the front panel
LCD Settings menu. All units ship from the factory with a default DID of 0.
Device Types and Device IDs by model are as follows:
Model Device Type Device ID
880 1 0-B
TH20 2 0-F
VH20 E 0-F
840T 3 0-B
8i A 0-B
880T D 0-B
880TA H 0-B
SR 1212 G 0-B
SR 1212A I 0-B
Beamformer N 0-F
For example, if there are two CONVERGE Pro 880s and one 840T in a site, the 880s must have unique DIDs. They
could be assigned DIDs of 0 and 1 respectively, while the 840T could be assigned a DID of 0 without any conflicts.
NOTE: You must disconnect from the site in order to set the Device ID. Press the Disconnect
button on the Button Bar.
NOTE: The DID specified in Console MUST match the DID set for that unit in the LCD Settings
Menu. Otherwise when you reconnect to the site, Console will correctly recognize the unit
with the correct DID, but it also adds a duplicate unit with the incorrect DID.
Audio Master
Select Slave (default) or Master from the Audio Master drop down list. Audio Master units ignore audio from
upstream units in a site as shown in the sample stack below.
