Je bekijkt pagina 50 van 366

45

DID

The DID submenu allows you to select a Device ID for the unit. Select the DID you want to use, press the Select

button. Answer Yes to the prompt to change the DID, or No to keep the existing setting.

You can also use the General tab of the Unit Properties screen in Console to change this setting when disconnected

from the unit. However, DID assignments made in Console must match DID assignments made using the front

panel.

Default

Default restores ALL settings to their factory default values. Answer Yes to the prompt to restore default settings, or

No to retain the existing settings.

Contrast

Contrast allows you to change the LCD contrast level. Use the Menu Dial to adjust the contrast level, then press

the Select button to save it.

Version

Version displays all relevant version data related to the device.

SIP

SIP Displays which Proxy Settings are currently enabled on the VH20.

For more information, see the Table of Contents for these related topics:

• LCD Programming Overview

• LCD Channels Menu

• LCD Macros Menu

• LCD Presets Menu

• Site Properties

• String Tab

• Unit Properties

LCD MACROS MENU

The LCD Macros Menu allows you to run macros from the front panel. To record Macros, use the Macro Tab in

Console.

Accessing the Macros Menu

To access the Macros menu, press the Select Button on the front panel, use the Menu Dial to select Macros, and

press the Select Button.

The Macro Menu appears as shown below:

MACRO MENU

1-Gain Adjust 7-8

2-UnProgrammed

3-UnProgrammed

4-UnProgrammed

5-UnProgrammed

6-UnProgrammed

7-UnProgrammed
