42
LCD CHANNELS MENU
The LCD Channels Menu allows you to adjust the gain level and turn mute on or off for all channels.
Accessing the Channels Menu
To access the Channels menu, press the Select button on the front panel, use the Menu Dial to select
Channels, and press the Select button.
The Channels menu appears as shown below:
CHANNELS PAGE 1/2
Mics
Inputs
ProcessOutputs
Channels menu options (i.e. channel types) include:
• Mics
• Inputs
• Outputs
• Process
• Faders
• Telco/VoIP Tx
• Telco/VoIP Rx
• Pwr Amp
After you select an option, a list of all available channels of that type is displayed. Use the Menu Dial to select the
channel you want to configure and press the Select button. The Channels display appears.
Channel Display
The channel display is identical for every channel type, with the exception of the channel ID and channel label, which
both vary depending on the channel selected.
As shown below, the display includes a peak-level meter, a peak dB reading, a gain level adjustment box, and a
mute selector.
Meter
Gain
dB Mute Off
1-Input 1
dB
-50
+0
