INTRODUCTION TRANSMIG 4RT
Manual 0-5245 2-3 INTRODUCTION
2.05 Description
The Transmig 4RT Wirefeeder is fully compliant to Stan-
dard IEC 60974.5.The Transmig 4RT Wirefeeder when
used in conjunction with the Transmig 250i, Transmig
350i, Transmig 450i or Trnasmig 550i Multi Process Weld-
er provides excellent MIG welding performance across a
broad range of applications when used with the correct
welding consumables and procedures. The instructions
in the next section detail how to correctly and safely set
up the machine and give guidelines on gaining the best
efficiency and quality from the Power Source. Please read
these instructions thoroughly before using the unit.
2.06 User Responsibility
This equipment will perform as per the information con-
tained herein when installed, operated, maintained and
repaired in accordance with the instructions provided.
This equipment must be checked periodically. Defective
equipment (including welding leads) should not be used.
Parts that are broken, missing, plainly worn, distorted or
contaminated, should be replaced immediately. Should
such repairs or replacements become necessary, it is
recommended that such repairs be carried out by appro-
priately qualified persons approved by CIGWELD. Advice
in this regard can be obtained by contacting an Accredited
CIGWELD Distributor.
This equipment or any of its parts should not be altered
from standard specification without prior written approval
of CIGWELD. The user of this equipment shall have the
sole responsibility for any malfunction which results from
improper use or unauthorized modification from standard
specification, faulty maintenance, damage or improper re-
pair by anyone other than appropriately qualified persons
approved by CIGWELD.
2.07 Transportation Methods
!
WARNING
ELECTRIC SHOCK can kill. DO NOT TOUCH
live electrical parts. Disconnect input power
conductors from de-energized supply line
before moving the welding power source.
!
WARNING
FALLING EQUIPMENT can cause serious per-
sonal injury and equipment damage.
Lift unit with integrated handle at the top of the unit.
Use handcart or similar device of adequate capacity.
If using a fork lift vehicle, place and secure unit on a proper
skid before transporting.
2.08 Packaged Items
Transmig 4RT Wirefeeder
(Part No. W3000600)
•Transmig4RTWirefeeder
•OperatingManual
•DriveRoll0.9-1.2mm,VGrooveFitted
•OutletGuide0.9-1.2mm,Fitted
