4T LATCH MODE
This mode of welding is mainly used for long welding runs to
reduce operator fatigue. In this mode the operator can press
and release the MIG Gun trigger and the output will remain
active. To deactivate the power source, the MIG Gun trigger
switch must again be depressed and released, thus eliminating
the need for the operator to hold the MIG Gun trigger.
VOLTS INDICATOR
When illuminated the Value showing on the Right Hand Digital
Display is Volts.
MPM INDICATOR
When illuminated WFS (Wire Feed Speed) is selected and the
value showing on the Right Hand Digital Display is MPM (Metres
Per Minute).
E
MENU BUTTON
PRESS THE MENU BUTTON TO ACCESS ADVANCED SETTINGS
Press the Menu Button then the Forward and Back Menu Arrow
Buttons to cycle through the Advanced Settings. Use the Right
Control Knob to set values.
PRE GAS (PEG)
Shielding Gas ows for the time specied before an arc is
initiated.
Press the Menu Button then the Forward and Back Menu Arrow
Buttons to cycle through the Advanced Settings until reaching
Pre Gas (PEG). Once selected use the Right Control Knob to set
the desired value. This parameter has an adjustment range of
0 - 20 seconds.
Factory setting for Pre Gas is 0 seconds.
Once set exit Advanced Settings by pressing the Menu Button
and the Menu indicator will turn off.
POST GAS (PTG)
Shielding Gas ows for the time specied after an arc has
extinguished.
Press the Menu Button then the Forward and Back Menu Arrow
Buttons to cycle through the Advanced Settings until reaching
Post Gas (PTG). Once selected use the Right Control Knob to set
the desired value. This parameter has an adjustment range of
0 - 20 seconds.
Factory setting for Post Gas is 0.5 seconds.
Once set exit Advanced Settings by pressing the Menu Button
and the Menu indicator will turn off.
BURNBACK (BBT)
The Burnback Control is used to adjust the amount of MIG wire
that protrudes from the MIG Gun after the completion of MIG
welding (commonly referred to as stick out).
Press the Menu Button then the Forward and Back Menu Arrow
Buttons to cycle through the Advanced Settings until reaching
Burnback (BBT). Once selected use the Right Control Knob to
set the desired value. This parameter has an adjustment range
of 0.01 – 0.5 seconds.
Factory setting for Burnback is 0.01 seconds.
Once set exit Advanced Settings by pressing the Menu Button
and the Menu indicator will turn off.
CRATER FILL (CRF)
The Crater Fill reduces the Welding Current (Wire Feed Feed
Speed and Voltage) at the end of the weld over a period of
time (user adjustable) to ll and nish the end of the weld
eliminating craters from the weld .
Craters at weld ends can be a starting point for cracking.
CRATER FILL IN 2T TRIGGER MODE
When Crater Fill is turned On the operator is able to use Crater
Fill to complete the weld. In Trigger 2T mode the operator
can engage Crater Fill by following this procedure. Press and
hold trigger to weld then release the trigger to nish the weld
and within 0.4 seconds (press-release, press-hold trigger) to
enable Crater Fill. Whilst the trigger is held depressed the weld
will continue with the set Crater Fill parameters and will stop
once the trigger is released. If Crater Fill is not required simply
nish your weld by releasing the Trigger.
Note: If Crater Fill is turned ON and the weld is nished without
engaging the Crater Fill trigger sequencing it will continue to
weld for a period of 0.4 seconds. This time allows for Crater Fill
Trigger sequencing to be engaged.
CRATER FILL IN 4T TRIGGER MODE
When Crater Fill is turned On the operator is able to use Crater
Fill to complete the weld. In Trigger 4T mode the operator
can engage Crater Fill by following this procedure. Press and
release trigger to weld then (press-release, press-hold trigger)
to enable Crater Fill. Whilst the trigger is held depressed the
weld will continue with the set Crater Fill parameters and will
stop once the trigger is released. If Crater Fill is not required
simply nish your weld by pressing and releasing the Trigger.
Note: If Crater Fill is turned ON and the weld is nished without
engaging the Crater Fill trigger sequencing it will continue to
weld for a period of 0.4 seconds. This time allows for Crater Fill
Trigger sequencing to be engaged.
52 | CIGWELD.COM.AU
OPERATING MANUALBLUEVENOM 4R-ROVER
