5.15 MIG MANUAL MODE
A
B
C
D
E
Figure 5-19: MIG Manual Mode
A
MODE SELECTION BUTTON
Select Remote Feeder, Spool Gun or Push-Pull Gun mode.
B
PROCESS SELECTION BUTTON
Select MIG Manual mode.
C
LEFT CONTROL KNOB
PRESS TO STEP THROUGH AND SELECT OPTIONS IN MIG
MANUAL MODE
Turn clockwise to increase or counterclockwise to decrease
Wire Feed Speed (WFS) value.
D
RIGHT CONTROL KNOB
PRESS TO STEP THROUGH SELECTIONS AND SELECT OPTIONS
IN MIG MANUAL MODE
Inductance, Trigger Mode (2T/4T), and
Volts Trim.
INDUCTANCE
The Inductance (arc) control operates in MIG (GMAW) modes
The Inductance (arc) control operates in MIG (GMAW) modes
only and is used to adjust the intensity of the welding arc.
Higher arc control settings make the arc softer with less weld
spatter. Lower arc control settings give a stronger driving arc
which can increase weld penetration. This parameter has an
adjustment range of -10 to 10.
Factory setting for Inductance is 0.
TRIGGER MODE
SELECT TRIGGER MODE BUTTON
The trigger mode control is used to switch the functionality of
the MIG Gun trigger between 2T (normal) and 4T (latch mode).
2T NORMAL MODE
In this mode, the MIG Gun trigger must remain depressed for
the welding output to be active. Press and hold the MIG Gun
trigger to activate the power source (weld). Release the MIG
Gun trigger switch to cease welding.
OPERATING MANUAL BLUEVENOM 4R-ROVER
CIGWELD.COM.AU | 51
