DIMENSIONS / SPECIFICATIONS
CICADA AUDIO PRO COAX HORN DRIVERS
The LATEST AND GREATEST series of CoAx Horn drivers features and specifications are on the next few pages.
Makes sure to read this manual thoughly and get to know your drivers and the many applications and possible set up
scenarios available to you. For your reference - Theile/Small parameters and RTA curves are on page 11 and 12.
6.2”/ 158.0mm
CH65.4 / CH65.2
• 6.5” PRO Full-Range Co-Ax Horn Speaker
• 500W RMS / 1000W MAX Power Handling
- Pair
• High Temp NEO N35H Magnet Structure
• Heavy Duty Cast Aluminum Basket
• 2” (50mm) Single Layer High-Temp Voice Coil for Woofer
• 1.4” (35mm) Single Layer High-Temp Voice Coil for Tweeter
• Frequency Response: 75Hz -20Khz +/- 5dB
• High Sensitivity: 96.4dB / 99dB Average (1W/1M - 2.83V)
• 12dB 2nd Crossover with Custom Tooled /Vented Case
6.5”/ 165mm
3.0”/ 76.2mm
CH8.4 / CH8.2
3.9”/ 99.0mm
• 8.0” PRO Full-Range Co-Ax Horn Speaker
• 500W RMS / 1000W MAX Power Handling
- Pair
5.7”/ 144.8mm
• High Temp NEO N35H Magnet Structure
• Heavy Duty Cast Aluminum Basket
• 2” (50mm) Single Layer High-Temp Voice Coil for Woofer
• 1.4” (35mm) Single Layer High-Temp Voice Coil for Tweeter
• Frequency Response: 75Hz -20Khz +/- 5dB
• High Sensitivity: 97.2dB / 101dB Average (1W/1M - 2.83V)
• 12dB 2nd Crossover with Custom Tooled /Vented Case
7.8”/ 197.5mm
8.3”/ 210.5mm
3.6”/ 91.2mm
3.9”/99.0mm
7.1”/180.0mm
2021 Cicada Audio All rights reserved.
3
