EN
Extraction version
The fumes are expelled to the outside using a series of pipes (sold
separately) attached to the included connecting flange.The diameter
of the exhaust pipes must match the diameter of the connecting ring:
for rectangular outlets, 222 x 89 mm, and for circular outlets, Ø 150mm
(*).
- for rectangular outlets 222 x 89 mm
- for circular outlets Ø 150 mm (*)
For more information on using the evacuation version, refer to the
relevant page in the illustrated section of the manual. When connecting
the product to wall-mounted exhaust pipes and holes, make sure the
diameter matches the air outlet (connecting flange). Using pipes and
holes with a smaller diameter may decrease the extractor's efficiency
and increase noise levels. For best results, keep the duct as short as
possible with a minimum number of curves (maximum angle: 90°) and
avoid sudden changes in duct diameter.
●Keep duct as short as possible.
●Use ducting with the least possible number of curves (maximum angle:
90°).
●Avoid drastic changes in the ducting diameter.
3. Installation
●Both the electrical and mechanical installation must be performed by
qualified professionals. This electrical appliance is designed to be
installed into a worktop with a thickness between 2 to 6 cm for a top
installation, or 2.5 to 6 cm for a flush installation. When installing the
hob, keep a minimum distance of 5 cm in front, 4 cm on the sides, and
50 cm from overhead wall units. Note: The recommended distances are
provided as examples only. When planning your kitchen, follow the
guidelines provided by the kitchen manufacturer.
8
