Installation
1) Based on the width of your hood, measure to find the center of the
wall. Mark a line and measure to the left and right to find your two
mounting points. Make sure the mounting points are level and mark
the with a pen.
Spirit Level Ruler
30"~36"
9
2) Poke the 7 perforated positions on the 1:1 Installation Diagram, then
align with the center point of aluminum grease filter on the
Installation Diagram with the horizontal line on the wall, then tape
the Installation Diagram to the wall, and use a pencil to mark the
perforated positions on the wall in the corresponding positions.
1:1 Installation Diagram
Tape
COMPONENTS:
Part 7: 1 :1 Installation Diagram
9
